Linear LED Surface Mount Panel Light
- By
- On 2024-10-15
5CCT & 3 Wattage Selectable
120Vac with 100lm/w, Traic Dimmable
120-277Vac with 110lm/w, 0-10V Dimmable
Nine Sizes 4"*2',6"*2',1'*2',2'*2',4"*3',6"*3',4"*4',6"*4',1'*4',
120Vac Triac & 120-277Vac 0-10V Dimming 2 in 1
| MODEL | POWER | VOLTAGE | LUMENS | DIMMABLE | CCT | DIMENSI0N(WxD) |
| AL15 | 22W | 120-277Vac | 2200lm/2420lm | Triac/0-10V | 5CCT | 4"x2' |
| AL15 | 22W | 120-277Vac | 2200lm/2420lm | Triac/0-10V | 5CCT | 6"x2' |
| AL15 | 22W | 120-277Vac | 2200lm/2420lm | Triac/0-10V | 5CCT | 1'x2' |
| AL15 | 30W | 120-277Vac | 3000lm/3300lm | Triac/0-10V | 5CCT | 2'x2' |
| AL15 | 30W | 120-277Vac | 3000lm/3300lm | Triac/0-10V | 5CCT | 4"x3' |
| AL15 | 30W | 120-277Vac | 3000lm/3300lm | Triac/0-10V | 5CCT | 6"x3' |
| AL15 | 20/30/40W | 120-277Vac | 4000lm/4400lm | Triac/0-10V | 5CCT | 4"x4' |
| AL15 | 20/30/40W | 120-277Vac | 4000lm/4400lm | Triac/0-10V | 5CCT | 6"x4' |
| AL15 | 20/30/40W | 120-277Vac | 4000lm/4400lm | Triac/0-10V | 5CCT | 1'x4' |
